intake and exhaust???

Posted By: blacknight On: 03-19-2008 @ 15:00:13         Reply | Edit
on a 78 firebird with a 305 chevy

how can I tell which rocker arms belong to intake and exhaust?

**I was once told the rockers closer to the manifold are intakes, but they are in a straight line on my car, so I cant tell. any help will be grateful.

thanks for your help

BOB

Posted By: fast82Z On: 03-20-2008 @ 11:30:47     Reply | Top | Edit
How bout this makeshift diagram, E being exhaust rocker, I being intake rocker.

front of car
E
I
I
E
E
I
I
E
--
1982 Z28, 383, D-1SC intercooled @ 10psi, trick flow heads, solid roller cam, 3.73's, stall
9.97@137, 1.48 60', 633rwhp@7400, 472rwtq@6800 AIM:CHATV400


Posted By: needaTA On: 01-27-2009 @ 15:33:49     Reply | Top | Edit
Well, you could look at the ports. The exhaust valve and rocker will be in line with the exhaust port. And the intake valve and rocker will be in line with the intake ports.

Or you could use that diagram. And it is completely universal! the valves are in the same order no matter which way you look at the engine from front to back, or back to front hahaha
